FRP / GRP pipe machine

Production Line of FRP Process Pipe Performance Characteristics: Production Line of FRP Cable Protection Duct Equipment Type Item Name DL300-1 DL300-2 DL300-4 Pipe diameter,IDmm DN50-DN300 DN50-DN300 DN50-DN300 Number of winding shaft,(product number manufactured in one time) 1 2 4 Winding angle 30º90º 30º90º 30º90º Product length,mm ≤6200 ≤6200 ≤6200 Rotating speed of maiThis n shaft,r/min ≤120 ≤120 ≤120 Transmission method Pinion and rack Pinion and rack Pinion and rack Control method manualsemi automaticautomatic manualsemi automaticautomatic manualsemi automaticautomatic Speed of winding vehicle,m/min 40 40 40 Precision of lining up yarn,mm ±1 ±1 ±1 Repositioning accuracy,mm 0.2 0.2 0.2 Max speed of pulling yarn,m/min 75 75 75 Max width of yarn tape,mm 120 120 120 Type of adding mortar Choose one type from mortar-adding at the top or mortar-adding at the bottom Choose one type from mortar-adding at the top or mortar-adding at the bottom Choose one type from mortar-adding at the top or mortar-adding at the bottom Winding type Reciprocating cross, hoop direction Reciprocating cross, hoop direction Reciprocating cross, hoop direction Winding roving capacity,each 22 44 44 Resin type Unsaturated polyester Unsaturated polyester Unsaturated polyester Cure type of pipe, normal temperature cure Infrared heating cure station can be chosen Infrared heating cure station can be chosen Infrared heating cure station can be chosen Demoulding type of pipe Chain traction demoulding of mechanical type Chain traction demoulding of mechanical type Chain traction demoulding of mechanical type Yarn framewinding yarn is a kind of inner pulling yarn Tension adjustable yarn frame of mechanical type Tension adjustable yarn frame of mechanical type Tension adjustable yarn frame of mechanical type Production capacity ,kg/h 200 350 500 Total installed capacity, kw 9.5not contain the heating cure station 10.5not contain the heating cure station 11.5not contain the heating cure station Areas covered by production linelength × width × heightm 9.5×9×1.2 18×10×1.2 18×10×1.6Series FRP process pipe production line of DL300 type is used to produce and manufacture FRP winding pipes as well as FRP cable protection ducts. The production line is featured by the high precision of winding line, high productivity, low energy-consuming, easy installation, adjustment and maintenance. It adopts the industrial computer control, so the usage and operation are very convenient. DL300-2 type can produce 2 FRP cable protection ducts of DN150×5mm every 6 minutes. DL300-4 type can produce 4 FRP cable protection ducts of DN150×5mm every 10 minutes Standard Collocation: Glass fiber winding machine/ 1 set Curing Station with two workstations/ 3 sets Trimming machine for pipe bell and spigot Pipe mold release machine of chain type Option Collocation: Resin pre-accelerated agitator tank Adjustable resin pump Adjustable catalyst flowmeter
